PVC/PE/PP Wood-Plastic Profile Extrusion Machine

1) Vacuum sizing tank have particular big eddy flow cooling system for cooling and sizing easy for high speed extruding necessary. 2) Different types of extroders can be selected for the production line according to the material properties. Special design for haul-off by particular up and down technology of our company, work stable, reliable and heavy duty force. 3) Advanced control system ensures the smooth running. Item SJYF1 SJYF2 SJYF3 ShapingTableLength(mm) 2100 4000 6000 VacuumPump(set) 1 3 4 Max.PumpingVolume(m/min) 0.48 10 12 CrossAdjustmentofShapingTable(mm) 80 40 80 Up-DownAdjustmentofShapingTable(mm) 100 200 60 Max.DrawingForce(N) 3000 25000 30000 Max.GripForce(N) 2500 15000 20000 DrawingSpeed(m/min) 0.3-4.5 0.4-6 0.4-4 Max.CuttingSize(mm) 100x70 210x160 210x120 TotalPower(dontincludingextruder)(kw) 5 29 35 AppearanceSize(LxWxH)(mm) 16000x1200x1600 24000x1500x1800 28000x1600x1800 Weight(kg) 2000 4500 6000
